RAG and Vector Databases

Introduction

Retrieval-Augmented Generation (RAG) is the most practical pattern for building AI applications with your own data. Vector databases are the enabling technology. Together, they solve the biggest limitations of Large Language Models (LLMs).

The Problem: LLM Limitations

LLMs Have Issues:

• Knowledge Cutoff — Training data has a date limit
• Hallucinations — Confidently generate false information
• No Access to Your Data — Don't know your documents, products, or policies
• Context Window Limits — Can't process millions of documents at once

RAG Solves These:

• Retrieves relevant information at query time
• Grounds responses in actual documents
• Works with any data you provide
• Scales to massive document collections

How RAG Works

RAG Flow:

1. Index Phase (Offline):

   • Split documents into chunks
   • Generate embeddings for each chunk
   • Store embeddings in vector database

2. Query Phase (Online):

   • User asks a question
   • Generate embedding for question
   • Search vector DB for similar chunks
   • Send question + retrieved chunks to LLM
   • LLM generates answer using the context

Visual Flow:

User Question
     ↓
[Generate Embedding]
     ↓
[Vector Search] → Top K relevant chunks
     ↓
[Augmented Prompt]
Question + Retrieved Context + Instructions
     ↓
[LLM Generates Response]
     ↓
Answer (with citations)

What Are Embeddings?

Embeddings convert text into numerical vectors that capture semantic meaning.

How They Work:

• Text goes into an embedding model
• Out comes a vector (array of numbers)
• Similar meanings = similar vectors
• Typically 384-1536 dimensions

Example:

"king" → [0.2, 0.5, -0.1, 0.8, ...]
"queen" → [0.3, 0.4, -0.1, 0.7, ...]  // Similar!
"banana" → [-0.5, 0.1, 0.9, -0.2, ...] // Different!

Popular Embedding Models:

• OpenAI: text-embedding-ada-002, text-embedding-3-small/large
• Azure: Azure OpenAI Embeddings
• Open Source: sentence-transformers, BGE, E5

Vector Databases

Vector databases store and search embeddings efficiently.

Why Not Regular Databases?

• Traditional DBs search by exact match or text patterns
• Vector search finds semantically similar content
• "How do I reset my password?" matches "Password recovery steps"
• Requires specialized indexes (HNSW, IVF)

Popular Vector Databases:

Purpose-Built:

• Pinecone — Managed, easy to use
• Weaviate — Open source, hybrid search
• Qdrant — Open source, Rust-based
• Milvus — Open source, highly scalable
• Chroma — Lightweight, Python-native

Vector Extensions:

• PostgreSQL + pgvector
• Elasticsearch with dense_vector
• Redis with RediSearch

Cloud Services:

• Azure AI Search (vector + keyword)
• Amazon OpenSearch with k-NN
• Google Vertex AI Matching Engine

Building a RAG System

Step 1: Document Ingestion

Documents (PDF, HTML, etc.)
     ↓
[Parse & Extract Text]
     ↓
[Chunk into segments]
     ↓
[Generate Embeddings]
     ↓
[Store in Vector DB]

Step 2: Chunking Strategy

Chunking is critical. Options:

• Fixed size (500-1000 tokens)
• Sentence boundaries
• Paragraph boundaries
• Semantic chunking (by topic)
• Overlap between chunks (100-200 tokens)

Step 3: Retrieval

# Pseudo-code
query_embedding = embed(user_question)
results = vector_db.search(
    query_embedding,
    top_k=5,
    filter={"category": "technical"}
)

Step 4: Generation

Prompt:
"Based on the following context, answer the question.
If the answer isn't in the context, say so.

Context:
{retrieved_chunks}

Question: {user_question}

Answer:"

RAG Optimization Techniques

Retrieval Improvements:

• Hybrid search (vector + keyword)
• Reranking retrieved results
• Query expansion/rewriting
• Metadata filtering
• Hierarchical retrieval

Chunking Improvements:

• Smaller chunks for precision
• Larger chunks for context
• Parent-child chunks (retrieve child, include parent)
• Overlapping chunks

Generation Improvements:

• Include source citations
• Use structured output
• Confidence scoring
• Iterative retrieval (ask followup questions)

Advanced RAG Patterns

Multi-Query RAG:

Original Question → [Generate variations]
                 → Query 1 → Results 1
                 → Query 2 → Results 2
                 → Query 3 → Results 3
                 → [Merge & Deduplicate] → LLM

Self-Querying: Let the LLM generate metadata filters:

"Find contracts from 2023 about AWS"
     ↓
{vector_search: "contracts AWS",
 filters: {year: 2023, type: "contract"}}

Agentic RAG: LLM decides what to retrieve:

Question → [Agent decides: search DB? call API? calculate?]
        → [Execute actions]
        → [Synthesize answer]

RAG vs Fine-Tuning

Use RAG When:

• Data changes frequently
• Need citations/traceability
• Data is large or varied
• Quick to implement
• Privacy-sensitive (data stays local)

Use Fine-Tuning When:

• Specific style or behavior needed
• Domain-specific terminology
• Smaller, stable dataset
• Performance is critical

Often Combined: Fine-tune for style/format, RAG for knowledge.

Cloud RAG Services

Azure:

• Azure AI Search (retrieval)
• Azure OpenAI (embeddings + generation)
• Azure AI Studio (orchestration)

AWS:

• Amazon Bedrock Knowledge Bases
• OpenSearch with k-NN
• Kendra (enterprise search)

Google Cloud:

• Vertex AI Search
• Vertex AI Matching Engine
• Enterprise Search on Gen App Builder

Common Pitfalls

Chunking Issues:

• Chunks too large (irrelevant content)
• Chunks too small (missing context)
• Breaking mid-sentence/thought

Retrieval Issues:

• Wrong embedding model for domain
• Not enough retrieved chunks
• No metadata filtering
• Ignoring keyword search

Generation Issues:

• Prompt doesn't instruct to use context
• Not handling "no answer found"
• No citation of sources
• Not validating outputs

Evaluation Metrics

Retrieval Quality:

• Precision@K — Relevant results in top K
• Recall@K — Found relevant items in top K
• MRR — Mean Reciprocal Rank

Generation Quality:

• Faithfulness — Answer supported by context
• Answer Relevance — Addresses the question
• Context Precision — Retrieved context was useful

Tools: Ragas, TruLens, LangSmith

Exam Relevance

For AI Certifications (AI-102, AWS ML):

• Know RAG architecture and components
• When to use RAG vs fine-tuning
• Embedding models and vector search
• Azure AI Search / Bedrock Knowledge Bases

For Solutions Architect:

• System design with RAG
• Choosing vector database
• Scaling considerations
• Cost optimization

Key Takeaway

RAG enables AI applications that use your data by combining vector search with LLM generation. The pattern is: embed and store documents → retrieve relevant chunks at query time → augment LLM prompt with context → generate grounded responses. Vector databases make semantic search possible. This is currently the most practical way to build AI applications with enterprise knowledge.
